Bag Size
Min. Bag Size (Width)
Gusset 55 mm / Flat 90 mm
Min. Bag Size (Length)
150 mm
Max. Bag Size (Width)
150 mm
Max. Bag Size (Length)
310 mm (Option: 420 mm)
Capacity
8 bags/min. * Depends on material and package type / size.
Packaging Method
Heat sealing
Dimensions
1,635 (W) x 1,415 (D) x 2,165 (H)
Weight
570 kg (Main Body)
Power Supply *
3-Phase / 200 V / 1.5 kW
Compressed Air *
250 L/min.
CE Marking **
Not Available
* Transformer for local voltage and dried compressed air to be prepared by the customer.
** Fail-safe design based on CE directive.
Bag Size
Min. Bag Size (Width)
Gusset 55 mm / Flat 90 mm
Min. Bag Size (Length)
150 mm
Max. Bag Size (Width)
150 mm
Max. Bag Size (Length)
310 mm (Option: 420 mm)
Capacity
12–15 bags/min. * Depends on material and package type / size.
Packaging Method
Heat sealing
Dimensions
1,600 (W) x 1,650 (D) x 1,960 (H)
Weight
750 kg (Main Body)
Power Supply *
3-Phase / 200 V / 2.2 kW
Compressed Air *
460 L/min.
CE Marking **
Not Available
* Transformer for local voltage and dried compressed air to be prepared by the customer.
** Fail-safe design based on CE directive.
